HARDWARE FEATURES |
|
Interface |
1 × 10/100 Mbps LAN/WAN Port
3 × 10/100 Mbps LAN Ports
2 × Standard SIM Card Slot |
|
Button |
Reset Button |
|
External Power Supply |
Power Adapter: Input Power 100-240v~50/60 Hz 0.6A
Output parameter 12VDC 1A |
|
Dimensions ( W x D x H ) |
220x141x31 MM(8.66x5.55x1.22 in) |
|
Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
|
Antenna |
4×external high gain antennas |
|
WIRELESS FEATURES |
|
Wireless Standards |
IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz |
|
Frequency |
2.4 GHz and 5 GHz |
|
Signal Rate |
300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz |
|
Wi-Fi Max.Associated Clients |
128 |
|
WAN Failover |
Yes |
|
Wireless Security |
WPA/WPA2, WPA-PSK |
|
Modulation technology |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16QAM@24Mbps, 64QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
MIMO-OFDM: MCS 0-31
MIMO-OFDM (11ac): MCS 0-9 |
|
CELLULAR FEATURES |
|
Module |
Qualcomm |
|
Band |
LTE-FDD: B2/B4/B5/B12/B13/B14/B66/B71
WCDMA: B2/B4/B5 |
|
Data Speed |
LTE DL/UL: 150Mbps/50Mbps
DC-HSDPA+DL/UL: 42Mbps/5.76Mbps
WCDMA: 384Kbps/384Kbps |
|
SOFTWARE FEATURES |
|
Channel adjustment |
Support |
|
Power adjustment |
Support |
|
Access restrictions |
Support |
|
SSID Hidden |
Support |
|
Speed limitation |
Support |
|
Black and white list |
Support |
|
User isolation |
Support |
|
Bandwidth limit |
Support |
|
DHCP |
Support |
|
VPN |
Support |
|
NRadio Cloud |
Support NRadio Connection and realize remote management. |
